High precision pressure sensor with high pressure jienlu
• Bland:jienlu
• Range: 0-100 Bar to 400 Bar
• Comprehensive Accuracy: 0.5%
• Output Signal: 0-10 VDC, 4-20 mA selectable
• Overload Pressure: 3 times
• Operating Temperature: 0℃ to 125℃
• Temperature Drift: ±0.02%/℃
• Supply Voltage: 24 VDC
• Electrical Connection: Original German Hirschmann connector
• Process Connection: G1/4, 1/4NPT, R1/4 connection options
The
PT101 pressure transmitter uses an imported Swiss sensor core, featuring a
compact design and easy installation. This product is especially suitable for
use in a wide range of pressure applications, offering excellent stability, a
broad temperature range, and a lifespan of over ten million cycles. It is
widely used in water pumps, injection molding machines, die casting machines,
and various types of hydraulic engineering machinery.
It is CE certified and can directly replace various similar imported products such as Atlas MSI, HUBA, Honeywell, Danfoss, Gefran, etc. OEM labeling can be done upon request.
